cocopar HG-245HCW 24.5-inch Gaming Monitor Instruction Manual

1.一般的な安全情報

デバイスをご使用になる前に、この安全に関する注意事項をよくお読みください。このマニュアルは、今後の参考のために保管してください。

• 火災や感電を防ぐため、モニターを雨や湿気にさらさないでください。
• モニターを開けないでくださいasing. 内部にはユーザーが修理できる部品はありません。修理はすべて資格のある担当者にご依頼ください。
• モニターが落ちないように、安定した平らな面に置いてください。
• モニター周囲の換気が適切であることを確認してください。通気口を塞がないでください。
• モニターに付属の電源アダプターのみを使用してください。
• モニターを長期間使用しない場合は、電源プラグをコンセントから抜いてください。
• 電源コードの上に重い物を置かないでください。
• Do not use abrasive cleaners or solvents on the monitor. Use a soft, damp 掃除用の布。
• Important Note for Type-C Connection: Static electricity may accumulate during monitor use with Type-C connections, potentially causing unstable connections (e.g., "no signal"). To ensure stable operation, it is recommended to connect an earth wire (grounding).

2.セットアップガイド

2.1 開梱とパッケージの内容

すべての部品をパッケージから慎重に取り出してください。以下のすべての部品が揃っていることを確認してください。

• モニターユニット
• 日本語取扱説明書
• Warranty and Repair Request Card
• スタンドポスト
• Base and Fixing Screws
• 電源アダプター
• HDMIケーブル
• DPケーブル
• タイプCからタイプCへのケーブル

No additional purchases are necessary as all required cables are included.

2.2 スタンドの組み立て

The monitor stand is designed for easy, tool-free assembly.

1. Insert Stand Post into Base: Insert the stand post into the base until it is securely seated.
2. Tighten Fixing Screw: Tighten the fixing screw located on the stand post to secure it to the base.
3. Attach Stand to Monitor: Insert the assembled stand into the slot on the back of the monitor until you hear a click, indicating it is locked in place.

Image: Step-by-step guide for assembling the monitor stand. It shows inserting the stand post into the base, tightening a screw, and then attaching the assembled stand to the back of the monitor.

2.3 VESAマウントの取り付け

The monitor supports VESA mounting (75mm x 75mm) for flexible placement options, such as wall mounting or attachment to a monitor arm. Compatible screws are M4 x 6mm to 8mm.

画像: 背面 view of the monitor highlighting the VESA mount points (75mm x 75mm) and showing the monitor's dimensions and tilt range.

2.4 デバイスの接続

The monitor features HDMI 2.0, DP 1.4, and USB Type-C ports, allowing connection to various devices including PCs, PS4/PS5, and Nintendo Switch. Built-in speakers provide audio without external speakers.

• HDMI接続： Use the provided HDMI cable to connect to devices like PCs, game consoles (PS4/PS5, Switch).
• DisplayPort (DP) 接続: Use the provided DP cable for high-refresh-rate connections to compatible PCs.
• USB Type-C接続: If your device's Type-C port supports video output (DP Alt Mode), use the provided Type-C to Type-C cable for video transmission. This port also supports up to 65W Power Delivery to charge connected devices. For Nintendo Switch, a single Type-C cable can connect without a dock. For iPad Air/Pro, it supports mirroring and extended display functionality (check Apple's official site for compatible models for extended display).
• オーディオ出力： 外部ヘッドフォンまたはスピーカーを 3.5 mm オーディオ ジャックに接続します。
• 力： Connect the power adapter to the DC power input.

画像: クローズアップ view of the monitor's input ports, including HDMI 2.0, DP 1.4, Type-C, Audio Out, and DC Power.

Image: The monitor connected to a laptop, smartphone, and Nintendo Switch via Type-C, demonstrating its versatility and charging capabilities.

3. 操作手順

3.1 電源のオン/オフと入力の選択

Use the power button (usually located on the back or bottom of the monitor) to turn the monitor on or off. The monitor can automatically detect the input source, or you can manually select it via the On-Screen Display (OSD) menu.

3.2 オンスクリーンディスプレイ（OSD）メニュー

The OSD menu allows you to adjust various monitor settings. Typically, buttons on the back or bottom of the monitor are used to navigate the menu. Common settings include brightness, contrast, color temperature, input source, and gaming features.

3.3 高いリフレッシュレートと応答時間

This monitor supports a maximum refresh rate of 200Hz and a fast 1ms (MPRT) response time, providing smooth and fluid visuals, especially beneficial for gaming. Features like FreeSync and Overdrive (OD) further enhance image clarity and reduce motion blur.

Image: Visual comparison demonstrating the smoothness of 200Hz refresh rate versus lower refresh rates (65Hz, 165Hz) in a racing game scene.

Image: Comparison of 5ms versus 1ms response time, showing significantly reduced motion blur and ghosting with 1ms.

3.4 Gaming Features (FreeSync, HDR, FPS Assist)

• フリーシンク: Reduces image tearing and stuttering for a smoother gaming experience.
• HDR: Provides higher contrast and a wider color gamut for more realistic images.
• FPS Assist Mode: Activate this mode with a single button press to display a crosshair on screen, aiding in FPS games.

Image: A first-person shooter game scene demonstrating the FPS Assist Mode with various crosshair options displayed on the screen.

3.5 IPSパネルと色性能

The non-glare IPS panel offers a wide 178° viewing angle, ensuring clear images from any perspective. With 350 nits brightness, a 1000:1 contrast ratio, 120% sRGB wide color gamut, and over 16.7 million display colors, it promises accurate color reproduction for an immersive visual experience.

Image: A vibrant image demonstrating the enhanced color reproduction with 120% sRGB, highlighting the richness and detail of colors.

3.6 Adjustable Display Modes

The monitor offers various display modes optimized for different content, including Game, Movie, FPS, RTS, and Internet browsing. Select the mode that best suits your current activity for an enhanced viewing の経験。

Image: A collage of different screen content (game, movie, internet, FPS, RTS) illustrating the monitor's various adjustable display modes.

4. メンテナンス

モニターの寿命を延ばし、最適なパフォーマンスを確保するには、次のメンテナンス ガイドラインに従ってください。

• 画面の掃除: 柔らかく糸くずの出ない布で画面を優しく拭いてください。頑固な汚れには、軽くamp布に水または画面専用の洗浄液を含ませてください。画面に直接液体を吹きかけないでください。
• Cのクリーニングasing: モニターの表面を拭くときは、柔らかく乾いた布を使用してください。asing. Avoid using harsh chemicals, abrasive cleaners, or solvents, as these can damage the finish.
• 換気： Ensure the ventilation openings on the monitor are clear of dust and debris to prevent overheating.
• 電源を切る： Always turn off and unplug the monitor before cleaning or when it will not be used for an extended period.

5。 トラブルシューティング

If you encounter issues with your cocopar HG-245HCW monitor, please refer to the following common solutions:

• No Signal / Unstable Connection (Type-C): If using a Type-C connection and experiencing "no signal" or unstable connection, it may be due to static electricity accumulation. It is highly recommended to connect an earth wire (grounding) for stable operation. Ensure your device's Type-C port supports video output (DP Alt Mode). Use the provided Type-C cable for optimal performance, as some third-party cables may only support power delivery.
• Refresh Rate Not Reaching 200Hz: The 200Hz refresh rate is the maximum supported. The default may be 60Hz. You must adjust the refresh rate settings on your connected device (PC, game console), not on the monitor itself. The maximum refresh rate achievable can vary depending on the specifications of the connected device and the connection method.
• PS4/PS5 Refresh Rate: The maximum output refresh rate for PS4/PS5 is 120Hz. Some games may only support up to 60Hz. Even for 120fps compatible games, the standby screen might remain at 60Hz, with 120Hz only active during gameplay scenes.
• Screen Appears Glossy / Marks on Screen: Before use, please peel off the protective film located on the upper right corner of the screen. This film is prone to dirt and scratches, which can appear as smudges, lines, or missing dots. Some films may also have inverted text imprinted on them. If this film is not removed, the screen may appear glossy.
• 電源なし: Ensure the power adapter is securely connected to both the monitor and a working power outlet. Verify the power outlet is functional.
• スピーカーから音が出ない: Check the volume settings on both the monitor and the connected device. Ensure the audio output is correctly routed to the monitor.

6. 仕様

7. 保証とサポート

cocopar is committed to providing excellent customer service and product quality.

• 品質保証： All products undergo thorough inspection before shipment.
• Initial Defects & Missing Accessories: In the unlikely event of initial defects or missing accessories, please contact us immediately. We will take full responsibility and provide appropriate support.
• お客様からのお問い合わせ: If you have any questions about the product, please feel free to contact us anytime. We are available via email and phone, not just through Amazon.
• 保証サービス: If a malfunction occurs within the warranty period (excluding damage due to improper use, and subject to necessary verification), we offer free parts or product exchange.

For further assistance, please visit the official cocopar store on Amazon: cocopar Amazon Store

8. 製品ビデオ

Watch these official videos for more information on the monitor's features and usage.
