導入
This manual provides essential information for the safe assembly, operation, and maintenance of your Garvee Oversized Manual Recliner Chair. Please read all instructions carefully before use and retain this manual for future reference.
安全情報
重要な安全上の注意事項:
- 最大重量：400ポンド。この制限を超えないでください。
- Keep children and pets away from the recliner mechanism.
- 使用する前に、すべての接続が安全であることを確認してください。
- フットレストやアームレストの上に立たないでください。
- Avoid placing fingers or hands near moving parts during operation.
- 使用していないときや清掃する前には、電源アダプターを抜いてください。
- Use only the provided power adapter for massage and heat functions.
組み立て手順
Estimated assembly time: Approximately 30 minutes. Two people are recommended for easier assembly.
パッケージ内容:
- 背もたれ
- アームレスト付きシートベース
- フットレスト
- マッサージリモコン
- 電源アダプター
段階的な組み立て:
背もたれを取り付ける: Align the metal brackets on the backrest with the receivers on the seat base. Push down firmly until you hear a click, indicating the backrest is securely locked into place.
Video: Garvee Recliner Chair Side Armrest Installation. This video demonstrates the process of attaching the backrest to the chair base, ensuring it locks securely.
Image: Attaching the backrest to the recliner chair. Ensure the brackets align and click into place.
電気配線を接続する: Locate the wires for the massage and heat functions. Connect the corresponding red-to-red and white-to-white wires. Then, connect the massage remote and power adapter to the main wiring harness.
Video: Garvee Recliner Chair Installation Guide. This video illustrates how to connect the electrical components for the massage and heat features.
Secure Side Panels (if applicable): If your model has removable side panels, ensure they are properly aligned and secured. Some models may have zippers to enclose wiring.
Image: Securing the side panel of the recliner. This step ensures all components are neatly enclosed.
操作手順
リクライニング機能:
To recline, locate the tab on the side of the chair (typically on the right). Pull the tab to release the footrest and lean back to your desired angle between 90° and 150°. To return to the upright position, push the footrest down with your legs and lean forward.
Image: Recliner positions for reading (90°), watching TV (120°), and napping (150°).
Massage and Heat Functions:
Use the provided remote control to activate and adjust the massage and heat features. The chair offers 5 massage modes and 8 vibration points. The heating function provides warmth to the lumbar area.
Video: Garvee Oversized Recliner Chair with Heat and Massage. This video shows how to operate the massage and heating features using the remote control.
Image: Massage and heat zones on the recliner, with the remote control for activation.
メンテナンス
クリーニング：
- For general cleaning, wipe the PU leather with a soft, damp 布。
- 素材を傷める可能性があるため、強力な化学薬品や研磨剤入りの洗剤の使用は避けてください。
- こぼした場合は、清潔で乾いた布ですぐに拭き取ってください。
一般的なケア：
- すべてのボルトとネジがしっかりと締まっているかどうかを定期的に確認してください。
- 素材の劣化を防ぐため、椅子を直射日光や熱源から遠ざけてください。
- Avoid sharp objects that could puncture or scratch the upholstery.
トラブルシューティング
| 問題 | 考えられる原因 | 解決 |
|---|---|---|
| Chair does not recline. | Reclining mechanism is jammed or not fully engaged. | Ensure the reclining tab is pulled completely. Check for obstructions around the mechanism. |
| マッサージ/ヒート機能が動作しません。 | Power adapter not connected or faulty; loose wiring connection. | Verify the power adapter is securely plugged into both the chair and a working outlet. Check all wire connections (red-to-red, white-to-white). |
| 椅子が不安定に感じます。 | 組み立てボルトが緩んでいます。 | Inspect and tighten all assembly bolts and screws. Ensure the backrest is fully locked into the base. |
仕様
| 特徴 | 詳細 |
|---|---|
| モデル名 | GV-RECLINER-M-PU-BEI |
| ブランド | ガービー |
| 色 | ベージュ |
| 材料 | Faux Leather, Sponge Filling |
| 製品寸法（奥行き×幅×高さ） | 奥行き37.4インチ x 幅41.7インチ x 高さ40.6インチ |
| シートの奥行き | 21.7インチ |
| 最大重量の推奨 | 400 ポンド |
| リクライニングポジション | 90° to 150° (3 positions) |
| 特集 | Adjustable Backrest, Arm Rest, Reclining, Side Pocket, Upholstered Leather, Massage & Heat Function (5 modes, 8 vibration points, lumbar heat) |
| アイテム重量 | 95ポンド |
Image: Detailed dimensions of the Garvee Oversized Manual Recliner Chair.
保証とサポート
For warranty information or technical support, please contact Garvee customer service. Refer to your purchase documentation for specific warranty terms and contact details.
返品規則： This product is eligible for a 30-day return policy from Amazon. Please refer to Amazon's return policy for details.
メーカー: ガービー
