ROBOWAY RW-RF037

ROBOWAY QIACHIP Wireless 433Mhz RF Module with 2 Button Remote (RW-RF037) Instruction Manual

Model: RW-RF037

1. はじめにview

The ROBOWAY QIACHIP Wireless 433Mhz RF Module with Mosfet and 2 Button White Remote (RW-RF037) is a versatile wireless control system designed for various applications. It features a compact design, high sensitivity, and non-directional wireless encoding technology to prevent interference. This module operates within a DC3.6V-DC24V range and supports a maximum load of 2A, making it suitable for controlling LED lights, fans, and other devices.

ROBOWAY QIACHIP Wireless 433Mhz RF Module and 2 Button Remote
Image 1.1: The ROBOWAY QIACHIP Wireless 433Mhz RF Module with its 2-button remote control. The module is a small circuit board with wires, and the remote has 'ON' and 'OFF' buttons.

2 製品の特徴

  • 柔軟な操作: Small size and high sensitivity for various control needs.
  • 耐干渉性: Utilizes non-directional wireless encoding technology for independent control.
  • ワイドVoltageサポート: Operates with DC3.6V-DC24V input.
  • 高耐荷重: Supports a maximum load of 2A.
  • 強力なRF信号: Capable of passing through walls, floors, and doors, with a reliable range of up to 200 meters (984ft with no obstacle).
  • 複数の作業モード: Supports Momentary, Toggle, Latched, and Delay modes.
  • 使いやすい: Simple learning and control process.
  • 多用途なアプリケーション: Ideal for DIY projects, LED lights, lamp beads, Christmas tree light strings, and light control switches.
Key features of the ROBOWAY RF Module
Image 2.1: An illustration highlighting the key features of the product, including 433MHz RF, EV1527 Learning Code compatibility, Fast & Silent MOSFET Switching, DC 3.6V - 24V Wide Voltage Support, 3 Working Modes (Momentary, Toggle, Latched), and up to 200 meters Long Control Distance. It also mentions applications for DIY, Home Automation, and Robotics.

3. セットアップとインストール

Follow these steps to set up your ROBOWAY QIACHIP Wireless RF Module:

  1. 接続電源： Connect the input wires (IN+ and IN-) to a DC power source within the 3.6V to 24V range. Ensure correct polarity.
  2. 接続負荷: Connect your device (e.g., LED, fan) to the output wires (OUT+ and OUT-).
  3. アンテナ： Ensure the antenna wire is properly extended for optimal signal reception.
  4. リモートのペアリング： The module typically comes pre-paired. If re-pairing or pairing a new remote is needed, locate the 'Learning Button' on the PCB board. Press and hold the learning button until the indicator LED responds (e.g., flashes). Then, press a button on the remote control to pair it. Refer to the specific mode setting instructions for detailed pairing procedures for each mode.
Wiring diagram for the 433MHz Wireless Control System
Image 3.1: A detailed wiring diagram showing the connections for the 433MHz wireless control system. It illustrates how to connect the input power (IN+ and IN-), the output load (OUT+ and OUT- to an LED), and points out the Learning Button and Antenna on the module.
Components of the ROBOWAY RF Module and Remote
Image 3.2: This image breaks down the components: the PCB board with an advanced smart control chip and high precision circuit design, the sensor wire (antenna) with up-to 200 meters range for fast and reliable response, and the modern 2-button remote with a clean design for smart control.

4。 動作モード

The ROBOWAY QIACHIP RF Module supports four distinct operating modes. The specific method to configure these modes typically involves pressing the learning button a certain number of times or for a specific duration. Please refer to the product packaging or additional documentation for precise mode setting instructions.

  • モーメンタリモード： The output is active only while the remote button is pressed. Releasing the button turns the output off.
  • モードの切り替え: Pressing the remote button once turns the output ON. Pressing the same button again turns the output OFF.
  • ラッチモード: Pressing one button on the remote turns the output ON. Pressing another button on the remote turns the output OFF. (Requires a remote with at least two distinct buttons for ON/OFF functionality).
  • 遅延モード: The output remains ON for a preset duration after the remote button is pressed, then automatically turns OFF. The delay time is usually configurable.
Applications of the ROBOWAY RF Module in various environments
Image 4.1: This image displays various application scenarios for the smart multi-device controller, including office lighting, LED installations, home automation, and car electronics, demonstrating its versatility.

5. 仕様

特徴 仕様
ブランド ROBOWAY
モデル番号 RW-RF037
営業巻tage DC3.6V-DC24V
最大負荷電流 2A
無線周波数 433MHz
制御範囲 Up to 200 meters (984ft with no obstacle)
コントローラータイプ ボタンコントロール
Button Quantity (Remote) 2
ネットワーク接続技術 無線周波数
商品の寸法 (長さ x 幅 x 高さ) 7L x 5W x 10H センチメートル
アイテム重量 200グラム
原産国 中国

6。 トラブルシューティング

  • デバイスが応答しない:
    • Check if the module is receiving power (DC3.6V-DC24V) and if the polarity is correct.
    • Ensure the load device is properly connected and functional.
    • Verify that the remote control battery is not depleted.
    • Confirm that the remote is correctly paired with the module. If unsure, attempt re-pairing.
  • Reduced Range or Intermittent Control:
    • Ensure the antenna on the module is fully extended and unobstructed.
    • Minimize physical obstructions (thick walls, metal objects) between the remote and the module.
    • 近くに強力な電磁干渉源がないか確認してください。
  • Remote Buttons Not Working:
    • Replace the remote control battery (Alkaline type).
    • Re-pair the remote with the module.

If you encounter any persistent problems during use, please contact ROBOWAY customer support for assistance.

7. メンテナンス

  • モジュールとリモコンは湿気や極端な温度を避け、乾燥した環境に保管してください。
  • 柔らかく乾いた布でデバイスを拭いてください。刺激の強い化学薬品や研磨剤入りの洗剤の使用は避けてください。
  • Regularly check the remote control battery and replace it when necessary to ensure optimal performance.
  • デバイスを落としたり、強い衝撃を与えたりしないでください。

8. 保証とサポート

For any product-related inquiries, technical support, or warranty information, please contact ROBOWAY customer service. You can reach them via the contact information provided by the manufacturer or retailer.

メーカー連絡先情報:
ROBOWAY, New Tech Enterprises, Property No. 8, Khasra No. 672, Kacchi Sadak, Metro Pillar No. 507 Mundka New Delhi, India 110041
Any B2B Enquiry Please Contact Us - 9041412414

輸入業者連絡先情報:
NEWTECH ENTERPRISES, PROPERTY NUMBER 8, KHASRA NUMBER 672, KACCHI SADAK, METRO PILLAR NUMBER 507 MUNDKA NEW DELHI DELHI India 110041
Any B2B Enquiry Please Contact Us - 9041412414
