eufy Security Floodlight Cam 2 User Manual

1. はじめに

The eufy Security Floodlight Cam 2 is an advanced outdoor security solution designed to provide comprehensive surveillance and illumination. Featuring 2K resolution, built-in AI for intelligent detection, two-way audio communication, and powerful 2,500-lumen floodlights, this device enhances the security of your property. It is weatherproof and compatible with eufy HomeBase 3, offering robust performance for various outdoor environments.

2. 箱の中身

• Floodlight Camera (Wired)
• 取り付けキット
• スクリューパック
• クイックスタートガイド

3. セットアップ

Installation of the eufy Security Floodlight Cam 2 requires existing outdoor wiring and a junction box. Please ensure power is disconnected before beginning installation.

図3.1: 前面 view of the eufy Security Floodlight Cam 2.

To complete the setup process, download the eufy Security app on your smartphone. Follow the in-app instructions to connect your Floodlight Cam 2 to your Wi-Fi network. Note that the device only supports 2.4GHz Wi-Fi.

Figure 3.2: The Floodlight Cam 2 installed, showing its two adjustable lights and central camera unit.

4. Operating the Floodlight Cam 2

4.1 ライブストリーミングと録画

The Floodlight Cam 2 allows you to live-stream and record in full 2K HD resolution, providing clear and detailed visuals of your monitored area.

Figure 4.1: Demonstrates the 2K resolution, capable of capturing fine details such as license plate numbers.

4.2 Floodlight Functionality

Equipped with 2,500-lumen super-bright motion-activated floodlights, the camera deters intruders and ensures detailed, full-color recordings even at night. The lights automatically activate when motion is detected.

Figure 4.2: The floodlight cam actively illuminating a dark outdoor space, demonstrating its night vision capabilities.

図 4.3: 元ample of the full-color night view, providing clear and vibrant images even in low-light conditions.

4.3 AI Human Detection and Smart Siren

The built-in AI intelligently detects human motion, reducing false alarms. A high-volume alarm can be triggered automatically or manually to scare off unwanted visitors.

Figure 4.4: The AI Human Detection feature actively identifying and highlighting a person within the camera's field of view.

4.4 ローカルストレージ

The Floodlight Cam 2 includes 4GB of built-in local storage for motion-triggered recordings, eliminating the need for monthly subscription fees. This capacity can store approximately 16 days of footage, assuming 30 video clips per day, each 1 minute in length.

Figure 4.5: An illustration representing the integrated local storage capability of the device.

4.5 Voice Control and Compatibility

The Floodlight Cam 2 supports integration with Amazon Alexa and Google Assistant, allowing for convenient voice control and monitoring of your outdoor space.

5. メンテナンス

The eufy Security Floodlight Cam 2 is designed with a weatherproof (IP65) rating, ensuring its durability and continued operation in various outdoor conditions. Regular cleaning of the lens and floodlight surfaces with a soft, damp cloth is recommended to maintain optimal performance and image clarity.

6. トラブルシューティングとよくある質問

• Can the floodlight camera record 24x7?
  No. The floodlight camera records motion-activated events. It has a longer detection range and supports a 10-second pre-buffer to ensure complete events are recorded.
• How does the 10s pre-buffer work?
  The floodlight camera stores a rolling 10 seconds of footage. When it detects an event, it starts recording and adds the previous 10 seconds to the beginning of the video.
• Does the floodlight camera support activity zones?
  Yes, the floodlight camera supports up to 2 activity zones. Users can set activity zones to exclude unnecessary event alerts or recording unnecessary footage.
• Does Floodlight Camera connect to eufyCam HomeBase?
  Yes, Floodlight Cam 2 is compatible with eufy HomeBase 3.
• Does the floodlight camera support Amazon Alexa and the Google Assistant?
  Yes, the floodlight camera supports Amazon Alexa and the Google Assistant.
• What’s the capacity of the internal storage? Can I upgrade it?
  The floodlight camera has 4GB local storage built-in for motion-triggered recordings. In the scenario of 30 video clips per day, 1 minute length per recording, the 4GB eMMC can store about 16 days of footage. The internal storage is not upgradeable.
• How to connect eufy Floodlight Cam 2 to Wi-Fi?
  Select eufy Floodlight Cam 2 through the eufy app, then follow the instructions to complete the setup. Please note that it only supports 2.4GHz Wi-Fi.
• Video Quality and Frame Rate:
  The eufy Floodlight Cam 2 records in 2K resolution at 15 frames per second (FPS). This provides higher detail compared to some other cameras that might record at 1080p but at a higher frame rate (e.g., 30 FPS). The choice between higher resolution and higher frame rate depends on specific surveillance needs.

7. 仕様

8. 保証とサポート

The eufy Security Floodlight Cam 2 comes with a 90日間の限定保証. For technical support, troubleshooting assistance, or warranty claims, please refer to the contact information provided in your Quick Start Guide or visit the official eufy Security webサイト。
